Product Details
- Size: 1230*700*1400mm
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: DZGZ
- Model Number: DZGF
- Weight: 500.000 kg
product features: 1.Colorful touch screen is convenient to control and the operation condition is clear at a glance.
Tilted feeding box provides a convenient facility for tube filling. A pinching board is installed beneath the feeding box to prevent the tube from blocking.
2.During the mechanical tube feeding, the tube is pressed into the holes of working dishes which are stable and reliable. You only need to adjust the accessory when the product is changed for another size.
3.Simultaneous positive pressure and negative pressure dust absorption system with longer cleaning time ensures a thorough cleaning result.
4.The precision of mechanical link system is within 0.2mm.
5.With unique service control, the filling can be adjusted freely by the touch screen.
6.Plug-in type trailing feeding starts from the bottom of the tube to prevent air from mixing with cream and reduce the possibility of product oxidation. Thus the quality of product can be ensured.
7.The machine can be rapidly heated.
8.Quick-replace type multi-function nip may perform vertical, circular and abnormal end sealing. The number of batch can be printed on both single and double sides and is convenient to change.
2.During the mechanical tube feeding, the tube is pressed into the holes of working dishes which are stable and reliable. You only need to adjust the accessory when the product is changed for another size.
3.Simultaneous positive pressure and negative pressure dust absorption system with longer cleaning time ensures a thorough cleaning result.
4.The precision of mechanical link system is within 0.2mm.
5.With unique service control, the filling can be adjusted freely by the touch screen.
6.Plug-in type trailing feeding starts from the bottom of the tube to prevent air from mixing with cream and reduce the possibility of product oxidation. Thus the quality of product can be ensured.
7.The machine can be rapidly heated.
8.Quick-replace type multi-function nip may perform vertical, circular and abnormal end sealing. The number of batch can be printed on both single and double sides and is convenient to change.
9.The smooth surface of machine has no dead angle and is easy to clean. The materials completely contact with the stainless steel and comply with GMP standard.
main technical parameter:
| voltage | ~220v,50Hz |
| power | 3kw |
| compress supply pressure | 0.6-0.8(Mpa) |
| filling volume(ml) | 50.100.150 |
| working capacity (pieces/min) | 20-30 |
| filling error | 1% |
| size(mm) | 1230*700*1400 |
| weight | 600kg |
- Size: 1230*700*1400mm
- Place of Origin: Jiangsu, China (Mainland)
- Brand Name: DZGZ
- Model Number: DZGF
- Weight: 500.000 kg
